Kernel Device/Driver API. More...

Collaboration diagram for Devices:

Modules
	ACPI

	Drivers
	Driver API.

	Network Device

	PCI

Data Structures
struct	device
	Represents a device inside the kernel. More...

Macros
#define	generate_device_rw_functions(_pfx, _dev_type, _reg_field, _off_type)
	Generate generic functions used to read/write a device's regsiters. More...

Functions
error_t	device_register (device_t *)
	Register a new device. More...

struct device *	device_find (const char *name)
	Find a registered device by name.

struct file *	device_open (device_t *)
	Open a device for interacting with it.

static void	device_set_name (struct device dev, const char name)
	Set the name of the device.

static const char *	device_name (struct device *dev)

Detailed Description

Devices

Philsophy

This device driver API is heavily inspired by Linux's one, as it is the only one I'm familiar with currently, and I like it.

Hardware interactions are split into two 3 parts:

The physical hardware (not our responsibility)
The driver
The device

Every interaction with a hardware component is done by interacting with its corresponding device.

Design

Devices come in many shapes (timers, buses, etc ...), and as such, the sets of functions used to communicate with a given hardware varies a lot. The different function groups (vtables) should be located inside the device struct (whichever one, depending on the type of hardware), and should stay hidden the driver.

The driver's only responsibility is to create, initialize and register the appropriate device device for its hardware. Once the device has been registered, it can be used to communicate with the underlying hardware.

Usage

The kernel automatically detects and keeps track of all the connected hardware devices. When a new device is detected, its corresponding driver is looked for in the list of curenlty loaded drivers. If a matching one has been found, it is requested to create the appropriate device.

See also: Drivers

Macro Definition Documentation

◆ generate_device_rw_functions

#define generate_device_rw_functions	(	_pfx,
		_dev_type,
		_reg_field,
		_off_type
	)

Value:

    __device_read(u8, b, _pfx, _dev_type, _reg_field, _off_type)               \
        __device_write(u8, b, _pfx, _dev_type, _reg_field, _off_type)          \
            __device_read(u16, w, _pfx, _dev_type, _reg_field, _off_type)      \
                __device_write(u16, w, _pfx, _dev_type, _reg_field, _off_type) \
                    __device_read(u32, l, _pfx, _dev_type, _reg_field,         \
                                  _off_type)                                   \
                        __device_write(u32, l, _pfx, _dev_type, _reg_field,    \
                                       _off_type)

The functions are named: prefix_[read,write][b,w,l]

Parameters

_pfx	The device's functions' prefix
_dev_type	The device's type
_reg_field	The name of the fields pointing to the device's registers
_off_type	The type used for the offset variable

@info _off_type must be indirectly castable into an integer

Function Documentation

◆ device_name()

static const char * device_name ( struct device * dev )

inlinestatic

Returns: The name of the device

◆ device_register()

error_t device_register ( device_t * dev )

The device must have been allocated and initialized first by its corresponding driver.
